HESC workshop is equipped with latest CNC Machines & Supporting Conventional Machines
CNC Turning Center
CNC Vertical Milling Machine
Die Sinker EDM Machine
EDM Wire Cut Machine
Injection Molding Machine
Pressure Die Casting Machine
Radial Drill Machine
Tool and Cut Grinder Machine
Universal Milling Machine
Bench Drill Machine
Cylindrical Grinder Machine
Induction Hardening Machine
CNC vertical machining centre
It is a machine tool used to machine solid materials. Milling machines can perform a vast number of operation some very complex, such as slot and key way cutting, planning, drilling, die sinking, rebating, routing etc.
CNC TURNING CENTRE
CNC lathes, are rapidly replacing the older production lathes (multi spindle, etc). Due to their ease of setting operation. They are designed to use modern carbide tooling & fully utilize modern processes. They part may be designed and the tool paths programmed by the CAD/CAM processes, and the resulting file uploaded to the machine, and once set and trailed the machine will continue to turn out parts under the occasional supervision of an operation.
CNC EDM die-sinker MACHINE
Electrical discharge machining is a machining method primarily used for hard metals or those that would be very difficult to machine with traditional techniques.
CNC EDM WIRE CUT MACHINE
Wire EDM machining (electrical discharge machine) is an electro thermal production processes in which a thin single-strand metal wire in conjuction with di-ionized water (used to conduct electricity) allows the wire to cut through metal by the use of heat from electrical sparks.
INJECTION MOLDING MACHINES
This machine is used for the manufacturing of the plastic products.
PRESSURE DIE-CASTING MACHINE
It is used for casting of metallic parts.
Muffle furnace is used for heat treatment that increase the strength and hardness of materials.
Universal milling machine
Milling machine is a machine tool used to machine solid materials. Milling machine exist in two basic form horizontal and vertical. Milling machine can perform a vast number of operations such as slot and key way cutting, planning, drilling, die-sinking, rebating, routing etc.
A lathe machine is a machine tool which spins a block of material to perform various operations such as cutting, sanding, knurling, drilling, or deformation with tools that are applied to the work piece to create an object which has symmetry about an axis rotation. Lathes are used in wood turning, metal working, metal spinning and glass working.
It is used for making slots, pinion and flat surface finishing for manufacturing purpose.
Surface grinder is used to produce a smooth finish on flat surface. It is widely used abrasive machining process in which spinning wheel covered in rough particles (grinding wheel) cuts chips of metallic or nonmetallic substance from a work piece making a face of it flat or smooth.
The cylindrical grinder is a type of grinding machine used to shape the outside of an object. This includes but is not limited to such shapes as a cylinder an ellipse, cam or a crankshaft.
TOOL & CUTTER GRINDER
It can be used to grind various tools & cutters such as milling tools, reamers, and pinion cutters.
Electroplating machine is used for coating a metal with a thin layer of another metal by electrolysis to improve the metal’s corrosion resistance. The main purpose of electroplating is to improve:
Protection against corrosion
Special surface properties
Engineering or mechanical properties
Few samples of electroplating process done at HESC are given below:
